Victron Phoenix Inverter - 48 VDC - 3000W - 230 VAC - 50/60Hz

SKU:
PIN483020000-VIC
|
UPC:
8719076023852
$1,079.99
$1,428.00
(You save $348.01 )
(No reviews yet) Write a Review

Phoenix Inverter - 48 VDC - 3000W - 230 VAC - 50/60Hz

Pure sine wave output, high peak power and high efficiency. Combined high frequency and line frequency technologies ensure the best of both worlds.

SinusMax - Superior engineering

Developed for professional duty, the Phoenix range of inverters is suitable for the widest range of applications. The design criteria have been to produce a true sine wave inverter with optimised efficiency but without compromise in performance. Employing hybrid HF technology, the result is a top quality product with compact dimensions, light in weight and capable of supplying power, problem free, to any load.

Parallel and 3-phase operation capability

Up to 6 Phoenix Inverters can operate in parallel to achieve higher power output. Six 24V 5000VA units, for example, will provide 24kW / 30kVA output power. Operation in 3-phase configuration is also possible.

Warranty Info

WarningWARNING: This product can expose you to chemicals which are known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov.

Specifications:

  • GFCI: No
  • DC Connection Type: Hardwire
  • AC Connection Type: Hardwire
  • Outlet Qty: None
  • Inverter Surge Rating: 6000w
  • Inverter Input Voltage: 38-66v
  • Inverter Cont. Output Wattage: 3000w
  • Waveform: Pure Sine Wave
  • Inverter Output Voltage: 230v
  • Box Dimensions: 12"H x 13"W x 18"L WT: 44.55 lbs
  • UPC: 8719076023852

Quick Guide (pdf)
Shipping Cost:
Calculated at Checkout
Width:
13.00 (in)
Height:
12.00 (in)
Depth:
18.00 (in)
