AC Main + 6 Positions / DC Main + 18 Positions
Switches Color: White
Installed AC Breakers
(1) 16A (3) 8AInstalled DC Breakers(1) 100A Main(12) 15A- Voltage 230v - 12/24V DC
- All AC and DC buses installed and fully pre-wired
- Label backlighting pre-installed
- ON - indicating LEDs installed in all circuit positions
- 100 Ampere C-Series Toggle Circuit Breaker provides main circuit protection and switching for DC branch
- Maximum panel amperage - 100 Amperes AC, 50 Amperes DC
WARNING: This product can expose you to chemicals including di(2-ethylhexyl)phthalate (dehp) which is known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov.
Specifications:
- Voltage: 230/12/24v
- AC/DC: Both
- Max Breaker Quantity: 6 AC / 18 DC
- Box Dimensions: 6"H x 14"W x 22"L WT: 10.25 lbs
- UPC: 632085085087
Quick Guide (pdf)Owner's Manual (pdf)
