Veratron LinkUp Intelligent Temperature Pressure

SKU:
B00070501-VER
|
UPC:
7640178729674
$171.89
$190.99
(You save $19.10 )
(No reviews yet) Write a Review

LinkUp Intelligent Temperature & Pressure

This Sensor measures simultaneously the engine oil's temperature and pressure while providing the data to the LinkUp, which translates it to the NMEA 2000® standard.

Features:

  • Interface to the new electronic 2-in-1 sensor
  • Oil Temperature and Pressure in a single sensor
  • Rugged and reliable design derived from the automotive field
  • ASIC-controlled sensor
  • PWM (Pulse Width Modulated) output to transmit both pressure and temperature

Technical Specifications:

  • M12 mounting thread
  • IP 69/K protection class
  • 5V power feed provided by the LinkUp
  • Temperature accuracy ± 1°K in the 135 °C – 160 °C range
  • Pressure accuracy ± 0.2 bar (range 0.5 –3 bar), ± 0.1 bar below and ± 0.3 bar above
  • Temperature range: -40 °C + 160 °C
  • Pressure range: 0.5 to 10.5 bar
  • 1M cable length
This product may not be returned to the original point of purchase. Please contact the manufacturer directly with any issues or concerns.


Owner's Manual (pdf)
Brochure (pdf)
Shipping Cost:
Calculated at Checkout
Width:
4.000 (in)
Height:
4.000 (in)
Depth:
17.000 (in)
