Raymarine i70s Sailing System Pack, Wind, Depth, Speed
i70s Multi Display E70327
Maximum Visibility and Maximum Versatility
The i70s multifunction gives you the flexibility to display instrument and
navigation data that is most important to you. Equipped with a bold and
bright 4.1_ display, the i70s is easy-to-customize with digital, analogue
and graphical displays of depth, speed, wind and more. Add the i70s to your
existing Raymarine instrument system or create a network of i70s displays
and sensors, the choice is yours.
*NMEA2000 certification pending. A DeviceNet to SeaTalknj adatop is required
for connecting the i70s to NMEA2000 backbone.
Intuitive LightHouse User Interface
The i70s places frequently used navigation functions right at your
fingertips. The LightHouse instrument interface is consistent with Raymarine
LightHouse multifunction displays, so Raymarine MFD users will feel right at
home with the i70s.
Raymarine i70s allows for connectivity to the following on board networks:
Display AIS targets from NMEA 2000 AIS receivers. View the closest 25
AIS-equipped vessels and select individual targets to obtain vessel
iTC5 Transducer Converter E70010
The iTC5 Instrument Transducer Converter enables the use of common analog
transducer signals with new digital instrument displays like Raymarine's i70
and ST70 Plus. The ultra-compact iTC5 has connections to host the five most
common analog transducers; depth, speed/temperature, wind, compass and
rudder. The iTC5 instantly converts these 5 analog signals to digital
In addition to providing analog-to-digital conversion, the iTC5 provides all
of the necessary power and communications connections to the transducers.
This greatly simplifies the installation of new systems, and also provides a
simple and cost-effective means for owners of older analog instrument
displays to upgrade to the latest digital display technology. The iTC5
eliminates the need for expensive "smart" transducers or individual
instrument pods. Complete control for calibration and alarms is performed
through the i70 or ST70 Plus instruments.
The iTC5 connects to Raymarine's SeaTalkng network and works with
most analog transducers from legacy Raymarine ST30, ST40, ST50, ST60, ST80
and ST290 series instruments. Additionally the iTC5 works with Raymarine
fluxgate compass modules as well as rotary and linear rudder feedback
transducers to support compass heading and rudder angle instruments.
Wind Vane E22078
Standard Forward Wind Transducer, Standard Length: 14 1/2" Includes 100ft. Cable.
DST800 Nylon Thru hull A22154
Raymarine DST800 Nylon Thru Hull Transducer with Depth, Speed, and Temp for
1ea E70327 i70s Instrument
1ea E70010 ITC-5
1ea A22154 DST800 Transducer
1ea E22078 Standard Wind Transducer
1ea A06031 Backbone Terminator
1ea A06074 Inline Terminator
1ea A06068 Backbone Cable 9M
1ea A06049 Power Cable
